Using , you can create interactive and engaging graphical applications that work with canvas. One of the highly customizable aspects of Fabric.js is the ability to change the default rotate icon. Fabric.js HTML5 To customize the rotate icon in Fabric.js, follow this comprehensive step-by-step guide to add a unique touch to your canvas-based projects. Step 1: Preparing the Icon Prepare the custom icon you want to use for the new rotate icon first. Assume you have an SVG icon named "custom_rotate_icon.svg". To convert the icon file into a Base64 encoded string, you can use the in JavaScript. FileReader API Here's an example code snippet to accomplish this: // Read the SVG icon file
const iconFile = "custom_rotate_icon.svg";

// Convert the file to a Base64 encoded string
const reader = new FileReader();
reader.onload = function (e) {
  const base64Icon = btoa(e.target.result);
  // Use the base64Icon string as the custom rotate icon
  // Proceed to Step 2
};
reader.readAsBinaryString(iconFile); Step 2: Integrating the Custom Icon In your Fabric.js code, locate the section where the rotate icon is defined. Typically, you'll find a constant variable named . Replace the existing Base64 encoded string with the one representing your custom icon. ROTATE_ICON Here's an example code snippet illustrating this integration: // Replace the existing rotate icon with the custom icon
const ROTATE_ICON = base64Icon; Step 3: Rendering the Icon Next, we'll define a rendering function that will be responsible for drawing the custom rotate icon on the canvas. Within the provided code, you'll find a function named . As a programmer, you can modify this function to suit your specific positioning and styling preferences. renderIcon() , where we customize the position and size of the icon: Consider the following example code snippet function renderIcon(ctx, left, top, styleOverride, fabricObject) {
  const size = 16;
  ctx.save();
  ctx.translate(left, top);
  ctx.rotate(fabric.util.degreesToRadians(fabricObject.angle));
  ctx.drawImage(imgIcon, -size / 2, -size / 2, size, size);
  ctx.restore();
} Step 4: Configuring the Control Now, we'll create a new control object that represents the rotation control, incorporating our custom icon. Within the provided code, you'll notice the creation of a control object named using . This object allows us to define various properties such as the position offsets, action handler, cursor style handler, connection options, action name, and the render function that will be responsible for rendering the control icon. mtr new fabric.Control() demonstrating the configuration of the control: Here's an example code snippet // Create the custom control object
const mtr = new fabric.Control({
  x: -0.6,
  y: 0.6,
  actionHandler: controlsUtils.rotationWithSnapping,
  cursorStyleHandler: controlsUtils.rotationStyleHandler,
  withConnection: true,
  actionName: 'rotate',
  render: renderIcon,
}); Step 5: Assigning the Custom Control The final step is to assign the newly created control object ( ) to the property of both and . This ensures that the custom control is available for all fabric objects and textboxes created within your application. mtr mtr fabric.Object.prototype.controls fabric.Textbox.prototype.controls illustrating this assignment: Consider the following code snippet // Assign the custom control to fabric.Object.prototype.controls
fabric.Object.prototype.controls.mtr = mtr;

// Assign the custom control to fabric.Textbox.prototype.controls
fabric.Textbox.prototype.controls.mtr = mtr; Conclusion: By meticulously following these comprehensive steps and incorporating your own custom icon, you can easily customize the rotate icon in Fabric.js to seamlessly blend with your design requirements. Whether you intend to add a personal touch or align the icon with your project's branding, the ability to customize the rotate icon provides unparalleled flexibility and enhances the visual appeal of your canvas-based applications. Don't hesitate to explore other customization options offered by Fabric.js to further tailor the library to your specific needs. Unleash your creativity and embark on a journey of creating remarkable canvas-based applications with Fabric.js!
