This is a simple gRPC communication between a web client and server with an Envoy proxy. I’m using the gRPC-Web library for this. gRPC-Web is a JavaScript client library that allows web applications to talk to gRPC services. Since browsers don’t support HTTP/2 or the binary protocol used by standard gRPC, gRPC-Web provides a way to bridge the gap by using HTTP/1.1 or HTTP/2 and encoding gRPC messages in a way that browsers can handle. Here’s how gRPC-Web works: 1- The client sends requests to the server using gRPC-Web, which typically uses HTTP/1.1 or HTTP/2. Metadata (like headers) can be attached to the request, such as for authentication (e.g., JWT tokens). The request is encoded in gRPC-Web format, typically using base64 encoding for the binary gRPC payload. The client sends this request over HTTP/1.1 or HTTP/2. 2- Envoy (or another reverse proxy like Nginx) sits between the gRPC-Web client and the gRPC server. Envoy receives the gRPC-Web request, decodes the gRPC-Web payload, and forwards it as a standard gRPC request to the gRPC server using HTTP/2. The gRPC server processes the request as if it were a native gRPC request, using HTTP/2. 3- The gRPC server processes the incoming gRPC request, does the business logic, and generates a response (in this case, the Go written application). The response is encoded in the standard gRPC format and sent back to Envoy. 4- Envoy receives the gRPC response, encodes it in gRPC-Web format (typically base64), and sends it back to the gRPC-Web client over HTTP/1.1 or HTTP/2. Any metadata in the gRPC response, such as status codes, is translated. 5- The gRPC-Web client decodes the response and uses the web application. NOTE: Client-side and Bi-directional streaming is not currently supported (see streaming roadmap) Advantages of gRPC-Web Browser Compatibility: Allows modern web applications to interact with gRPC services without needing native support for HTTP/2 and binary protocols. Efficiency: Leverages the performance and efficiency of gRPC while adapting it for the web. Here Is a Working Demo https://github.com/ehsaniara/gRPC-web-example Demo Quick Start docker compose up -d Then, open the browser on__http://localhost:8081__ (note: this demo uses 8081 and 8080 ports) Project Structure client/: Contains the gRPC-Web client code
server/: Contains the gRPC server code written in Go
envoy/: envoy configuration file Prerequisites Go
Node.js and npm
grpc-web
protoc compiler Proto File syntax = "proto3";

package helloworld;

option go_package = "./proto"; // Add this line

service Greeter {
  rpc SayHello (HelloRequest) returns (HelloReply);
}

message HelloRequest {
  string name = 1;
}

message HelloReply {
  string message = 1;
} Server Server’s main file (server/main.go): package main

import (
   "context"
   "google.golang.org/grpc/reflection"
   "log"
   "net"

   pb "github.com/ehsaniara/gRPC-web-example/proto"
   "google.golang.org/grpc"
)

type server struct {
 pb.UnimplementedGreeterServer
}

func (s *server) SayHello(ctx context.Context, in *pb.HelloRequest) (*pb.HelloReply, error) {
 return &pb.HelloReply{Message: "Hello " + in.Name}, nil
}

func main() {
 lis, err := net.Listen("tcp", ":50051")
 if err != nil {
  log.Fatalf("failed to listen: %v", err)
 }
 s := grpc.NewServer()
 pb.RegisterGreeterServer(s, &server{})

 // Register reflection service on gRPC server.
 reflection.Register(s)
 if err := s.Serve(lis); err != nil {
  log.Fatalf("failed to serve: %v", err)
 }

 log.Println("Server is running on port 50051")
 if err := s.Serve(lis); err != nil {
  log.Fatalf("failed to serve: %v", err)
 }
} Envoy Config ...
http_filters:
  - name: envoy.filters.http.grpc_web
    typed_config:
      "@type": type.googleapis.com/envoy.extensions.filters.http.grpc_web.v3.GrpcWeb
  - name: envoy.filters.http.cors
    typed_config:
      "@type": type.googleapis.com/envoy.extensions.filters.http.cors.v3.Cors
  - name: envoy.filters.http.router
    typed_config:
      "@type": type.googleapis.com/envoy.extensions.filters.http.router.v3.Router
... Web Client Client file (client/src/index.js ) // Import the generated gRPC-Web client stubs and message classes
import {GreeterClient} from './generated/helloworld_grpc_web_pb';
import {HelloRequest} from './generated/helloworld_pb';

// Create an instance of the Greeter client
const client = new GreeterClient('http://localhost:8080');

// Function to send a greeting request
function sayHello(name) {
    // Create a new request
    const request = new HelloRequest();
    request.setName(name);

    // Call the sayHello method on the Greeter client
    client.sayHello(request, {}, (err, response) => {
        if (err) {
            console.error('Error:', err.message);
            document.getElementById('output').textContent = 'Error: ' + err.message;
        } else {
            console.log('Greeting:', response.getMessage());
            document.getElementById('output').textContent = 'Greeting: ' + response.getMessage();
        }
    });
}

// Example usage: sending a request when the page loads
document.addEventListener('DOMContentLoaded', () => {
    const name = 'World';
    sayHello(name);
}); Run generate.sh to generate *_pb.js files, for which you need to have grpc-web and protoc-gen-js already installed in your machine. $ npm i grpc-web
$ npm install -g protoc-gen-js This will generate helloworld_grpc_web_pb.js and helloworld_pb.js files, which already exist in this demo. Here’s a related GitHub project: https://github.com/ehsaniara/gRPC-web-example?embedable=true This is a simple gRPC communication between a web client and server with an Envoy proxy. I’m using the gRPC-Web library for this. gRPC-Web is a JavaScript client library that allows web applications to talk to gRPC services. Since browsers don’t support HTTP/2 or the binary protocol used by standard gRPC, gRPC-Web provides a way to bridge the gap by using HTTP/1.1 or HTTP/2 and encoding gRPC messages in a way that browsers can handle. Here’s how gRPC-Web works: 1- The client sends requests to the server using gRPC-Web, which typically uses HTTP/1.1 or HTTP/2. Metadata (like headers) can be attached to the request, such as for authentication (e.g., JWT tokens). The request is encoded in gRPC-Web format, typically using base64 encoding for the binary gRPC payload. The client sends this request over HTTP/1.1 or HTTP/2. The request is encoded in gRPC-Web format, typically using base64 encoding for the binary gRPC payload. The client sends this request over HTTP/1.1 or HTTP/2. The request is encoded in gRPC-Web format, typically using base64 encoding for the binary gRPC payload. The client sends this request over HTTP/1.1 or HTTP/2. 2- Envoy (or another reverse proxy like Nginx) sits between the gRPC-Web client and the gRPC server. Envoy receives the gRPC-Web request, decodes the gRPC-Web payload, and forwards it as a standard gRPC request to the gRPC server using HTTP/2. The gRPC server processes the request as if it were a native gRPC request, using HTTP/2. The gRPC server processes the request as if it were a native gRPC request, using HTTP/2. The gRPC server processes the request as if it were a native gRPC request, using HTTP/2. 3- The gRPC server processes the incoming gRPC request, does the business logic, and generates a response (in this case, the Go written application). The response is encoded in the standard gRPC format and sent back to Envoy. 4- Envoy receives the gRPC response, encodes it in gRPC-Web format (typically base64), and sends it back to the gRPC-Web client over HTTP/1.1 or HTTP/2. Any metadata in the gRPC response, such as status codes, is translated. 5- The gRPC-Web client decodes the response and uses the web application. NOTE: Client-side and Bi-directional streaming is not currently supported (see streaming roadmap) NOTE: Client-side and Bi-directional streaming is not currently supported (see streaming roadmap ) streaming roadmap streaming roadmap Advantages of gRPC-Web Browser Compatibility: Allows modern web applications to interact with gRPC services without needing native support for HTTP/2 and binary protocols. Browser Compatibility : Allows modern web applications to interact with gRPC services without needing native support for HTTP/2 and binary protocols. Browser Compatibility Efficiency: Leverages the performance and efficiency of gRPC while adapting it for the web. Efficiency : Leverages the performance and efficiency of gRPC while adapting it for the web. Efficiency Here Is a Working Demo https://github.com/ehsaniara/gRPC-web-example https://github.com/ehsaniara/gRPC-web-example Demo Quick Start docker compose up -d docker compose up -d Then, open the browser on__ http://localhost:8081 __ (note: this demo uses 8081 and 8080 ports) http://localhost:8081 Project Structure client/: Contains the gRPC-Web client code server/: Contains the gRPC server code written in Go envoy/: envoy configuration file client/: Contains the gRPC-Web client code server/: Contains the gRPC server code written in Go envoy/: envoy configuration file Prerequisites Go Node.js and npm grpc-web protoc compiler Go Go Go Node.js and npm Node.js and npm Node.js and npm grpc-web grpc-web grpc-web protoc compiler protoc compiler protoc compiler Proto File syntax = "proto3";
