Generate Fancy Link Previews With Rails 7

May 10th 2022 1,025 reads
Read on Terminal Reader
Open TLDR
react to story with heart
react to story with light
react to story with boat
react to story with money
A ruby gem to transform HTML into PDFs, PNGs, or JPEGs using Google Puppeteer and Chromium is easy to use. We're going to build an HTML view and take a screenshot of it. We can create a blank HTML view, or just add additional functionality to your current app. We use the Ruby gem Grover and let Grover do the magic with a simple HTML/CSS/JSJS controller. Grover accepts a URL or inline HTML and. inline HTML. and optional parameters.

Hey hey heyyyyyy! Here’s a quick article on how to have beauty link previews, just like Dev.to does.


You're gonna get something like this:


Yup, was being literal with the "like dev.to" πŸ˜› I've built something similar for my new project workby.io, and here's how I did it...


Almost every guide that I found was using htmlcsstoimage.com, in fact, dev.to uses it. It's pretty popular and efficient, BUT, I don't want to pay $14 bucks for each 1k image πŸ˜‚πŸ


So, I'm going to use Grover: A ruby gem to transform HTML into PDFs, PNGs, or JPEGs using Google Puppeteer and Chromium.


If you want to build this with, let's say, Node.js, you can also follow me. Puppeteer is popular and easy to use.


Long story short: We're going to build an HTML view and take a screenshot of it.


You can create a blank Rails project, or just add additional functionality to your current app.

Setup

Install Grover gem with bundle add grover


And the dependency of Grover, Puppeteer, with: yarn add puppeteer


Then create an empty controller where you can respond with different link preview templates: rails g controller og-imager dev_to


In the dev_to action, let's call Grover and let him do the magic app/controllers/og_imager_controller.rb

class OgImagerController < ApplicationController
  # GET /og_imager/dev_to
  # @param {string} title
  # @param {string} avatar
  # @param {string} username
  # @param {string} timestamp
  # @param {array} logos
  # @returns image/png
  def dev_to
    # Get params and set to variable
    # TODO: Retrieve your object instead :p
    @title = params[:title]
    @avatar = params[:avatar]
    @username = params[:username]
    @timestamp = params[:timestamp]
    @logos = params[:logos]

    # Grover.new accepts a URL or inline HTML and optional parameters for Puppeteer
    grover = Grover.new(
      render_to_string
    )

    # Get a screenshot
    png = grover.to_png

    # Render image
    send_data(png, type: 'image/png', disposition: 'inline')
  end
end


Here's our view, just simple HTML/CSS app/views/og_imager/dev_to.html.erb

<div class="container">
  <div class="card">
    <h1 class="title">
      <%= @title %>
    </h1>
    <div class="details">
      <div class="user">
        <img src="<%= @avatar %>" class="avatar">
        <p class="username">
          <%= @username %> - <%= @timestamp %>
        </p>
      </div>
      <div class="logos">
        <% @logos.each do |logo| %>
          <img src="<%= logo %>" class="logo">
        <% end %>
      </div>
    </div>
  </div>
</div>

<style>
  @import url('https://fonts.googleapis.com/css2?family=Roboto:[email protected];500&display=swap');

  *{
    font-family: 'Roboto', sans-serif;
    color: #cd685f;
  }

  .container{
    width: 1128px;
    height: 600px;
    display: flex;
  }

  .card{
    display: flex;
    justify-content: space-between;
    flex-direction: column;
    margin: 2.8rem 4rem 4rem 2.8rem;
    border: 3px solid #c56b61;
    border-radius: 25px 25px 0px 0px;
    box-shadow: 7px 10px 0px 1px #c56b61;
    padding: 3.8rem 1.8rem 1.8rem 1.8rem;
  }

  .title{
    margin: 0px;
    font-weight: 500;
    font-size: 5rem;
    line-height: 80px;
  }

  .details{
    display: flex;
    justify-content: space-between;
  }

  .user{
    display: flex;
    align-items: center;
  }

  .avatar{
    border: 3px solid #c56b61;
    width: 50px;
    height: 50px;
    border-radius: 50%;
    margin-right: 10px;
  }

  .username{
    margin: 0;
    font-size: 2.5rem;
  }

  .logos{
    display: flex;
    justify-content: space-between;
  }

  .logo{
    width: 60px;
    height: 60px;
    margin-left: 20px;
    transform: rotate(5deg);
  }
</style>


And finally, create an initializer to set our Browser viewport (final image size).

initializers/grover.rb

Grover.configure do |config|
  config.options = {
    viewport: {
      width: 1128,
      height: 600
    },
  }
end


If you have created a blank project, and want to use this as a micro-service, here's a guide on how to deploy this thing to Heroku.

  1. Create the app on your Heroku account (I'm assuming you already have the cli installed): heroku create your_app_name
  2. Warn Heroku of our JS library (Puppeteer): heroku buildpacks:add heroku/nodejs --index=1
  3. And also help him to setup Puppeteer dependencies πŸ˜›: heroku buildpacks:add jontewks/puppeteer --index=2
  4. Tell Grover to run Puppeteer in the "no-sandbox": heroku config:set GROVER_NO_SANDBOX=true


To make use of this image on the link preview, you will need The Open Graph protocol. Just simple meta tags that browsers will look for.


Meta tags are always on <head> so, app/views/layouts/application.html.erb

<%= yield(:head) %>


And then ask ERB to fill the previous block with

<%= content_for :head do %>
  <meta property="og:title" content="<%= @article.title %>">
  <meta property="og:image" content="<%= article_link_preview(@article) %>">
  <meta property="og:image:type" content="image/png" />
  <meta property="og:image:width" content="1128">
  <meta property="og:image:height" content="600">
  <meta name="twitter:card" content="summary_large_image" />
<% end %>

at your details view. Like: /articles/:id


The twitter:card thing it's because they are fancier on link previews, you can read more about that here


The previous article_link_preview method it's a simple helper that generates the URL that we are looking for.

app/helpers/articles_helper.rb

def article_link_preview article
  uri = URI.parse('https://your_app_name.herokuapp.com/ogimage')
  uri.query = URI.encode_www_form(
    title: article.title,
    'images[]': article.tags.collect(&:image),
    timestamp: article.created_at.to_formatted_s(:short),
    ...
  )
  uri.to_s
end


You will get something like this: https://your_app_name.herokuapp.com/og_imager/dev_to?title=Real%20Time%20Notification%20System%20with%20Hotwire,%20in%20Rails%207&avatar=https://dev-to-uploads.s3.amazonaws.com/uploads/user/profile_image/369241/a0111bcb-a046-4398-98cd-f4cf0e2f8d0d.png&username=Matias%20Carpintini&timestamp=13%20April&logos[]=https://img.icons8.com/office/80/000000/ruby-gemstone.png&logos[]=https://practicaldev-herokuapp-com.freetls.fastly.net/assets/devlogo-pwa-512.png


Here's the repo of the whole thing.


This article was first published here.
