Fetching Large Logs from Loki in Kubernetes

Recently in my practice, I faced a significant challenge: extracting application logs per day from Loki in the Kubernetes environment. When cold, the application writes about 60 lines per minute, and when someone interacts with the application, it can write 2000-5000 lines of logs per minute – it turns out that was necessary to get more than 300,000 lines of logs. The setup did not include a configured log export, and the primary log viewing tool was Grafana, which imposes a 5000-line limit on log retrieval. Increasing this limit was not feasible as it would significantly strain our resources and was unnecessary for this one-time task. Additionally, accessing logs directly from the Kubernetes pod was not an option due to storage limitations within the pod itself.

So, I need to download logs directly from Loki without changing configurations.

Preparation

Used tools

• LogCli
• Kubectl

Additional steps

To ensure that the query will use to search for logs is correct, follow these steps:

1. Navigate to Grafana explore:
   • Go to Grafana > Explore
2. Set the required label:
   • Apply the necessary label to filter logs by the service.
3. Filter by date:

   • Use the operation filter to display lines containing the desired date.




Example query:

{instance="our-service"} |= `2024-07-12`

Execution

1. Install LogCli:

   • Download the LogCli binary from the Loki releases page

2. Set Loki address:

   • Configure the Loki address for LogCli using an environment variable:

   export LOKI_ADDR=http://localhost:8000


3. Port forwarding:

   • Forward local ports to the Loki pod to allow local access:

   kubectl --namespace loki port-forward svc/loki-stack 8000:3100


4. Extract logs:

   • Use LogCli to query and save the logs to a file:

   logcli query '{instance="our-service"} |= `2024-07-12`' --limit=5000000 --since=72h -o raw > our-service-2024-07-12.log


   • In this command:

     • --limit is set with a high value to ensure all logs are captured.

     • --since is set to 72 hours to cover a sufficient time range.




Conclusion

This entire process took approximately 10 minutes, resulting in a file with the complete application logs for the specified date. If needed, this process can be further optimized or automated.
