When it comes to incorporating irregularly shaped text into web projects, we often end up using images. However, there may be a better way – using inline SVG and CSS to create dynamic, responsive, and accessible graphics directly within our HTML. In this post, we'll walk you through the process of achieving this, ensuring our designs are on point while maintaining accessibility and SEO friendliness.

The Power of Inline SVG

Have you ever encountered design elements that you thought could only be achieved with externally sourced images? Something like this, for example:



Well, this may not be your only option. By leveraging inline SVG and some simple CSS, we can build captivating graphics right within our HTML documents. In this post, I'll show you exactly how to do this.

Working With SVG

To begin, you’ll need to start with a vector graphic of your design. Also, you’ll need to be able to edit it yourself in a vector graphics editor like Adobe Illustrator, or you’ll need to have someone who can help you do so. This is because we need to edit our images to add an invisible path for our text to be placed on. In my case, these were my original graphics:



I opened them up in Illustrator and added a path to each of them for the text to sit on. I placed the path for the first banner banner here.



For the purposes of this demo, I added a black stroke to it just so that you can see where the path is placed, but in the end, it will be invisible. As you can see, I made the path span the entire width of the main region of my banner so that the text can expand all along this path, accommodating phrases of varying lengths.


For the second banner, I did the same. Here’s where I placed the text path:



After your invisible text paths have been added, you’ll just need to export the banners as SVG. At this point, it's probably a good idea to optimize these SVG while you're at it. I like to use Jake Archibald's SVGOMG tool when doing this type of thing.

Creating the Inline SVG Banner

Now that you have your optimized SVG graphic with the invisible text path let's integrate it into your HTML. You'll want to paste it directly into our document:


<!DOCTYPE html>
<html>
  <body>
    <svg xmlns="http://www.w3.org/2000/svg" viewBox="0 0 691.3 201.8">
      <g id="banner">
        <path d="M148.6 79.6V21.7c-6.6-3.1-13.7-5.6-20.7-7.7C86.6 1.7 42.7-1.8 0 3.7c25.3 17.2 47.2 39.5 64.1 65.1-20.7 9.5-39.2 23.8-53.6 41.4C52 112.3 93 123.8 129.3 144l19.3-64.4zM549.7 121.8v57.9c45 16.4 94 22 141.6 16.2-27.4-15.1-50.8-37.4-67.1-64 13.4-3.9 26.3-9.4 38-16.9 10.6-6.7 20.2-15.1 28-24.8-39-3.5-77.1-15.7-114.3-28.4l-26.2 60z" class="st0"/>
        <path d="M105 46c0-13.7 11.2-24.8 24.9-24.6l18.7.3v46.5c-13.5-4.8-26.5-11.1-38.5-18.8L105 46zM549.7 179.7v-39.9c14.8 5.8 28.9 13.3 41.7 22.6 0 9.6-7.8 17.4-17.4 17.4h-24.3z" class="st1"/>
        <path d="M591.3 160.8v1.6c-26.5-19.1-58.4-31-90.9-35.1-45.1-5.7-91.4 3-133.2 20.8-35.8 15.2-69 37-106.5 47.3-52.4 14.5-111 4-155.7-26.8V46.1C149.7 77 208.2 87.4 260.7 73c37.5-10.3 70.7-32.1 106.5-47.3C409.1 7.8 455.3-.9 500.4 4.8c32.5 4.1 64.4 16 90.9 35.1v120.9z" style="fill:#3dc0d1"/>
      </g>
      <path id="text-path" d="M108.7 124.1c44.2 29 101 38.4 152 24.4 37.5-10.3 70.7-32.1 106.5-47.3 41.9-17.8 88.1-26.4 133.2-20.8 31.7 4 62.7 15.3 88.7 33.6"/>
    </svg>
  </body>
</html>


Now, we can add the text using a text node. And, Since we’re placing the text on a path, we’ll use a textPath element within our text node:


<svg xmlns="http://www.w3.org/2000/svg" viewBox="0 0 691.3 201.8">
  ...
  <path id="text-path" d="M108.7 124.1c44.2 29 101 38.4 152 24.4 37.5-10.3 70.7-32.1 106.5-47.3 41.9-17.8 88.1-26.4 133.2-20.8 31.7 4 62.7 15.3 88.7 33.6"/>
  <text>
    <textPath>Welcome Everyone!</textPath>
  </text>
</svg>


To link the text to the path in our graphic we add an href to our textPath referencing the id of the invisible path for our text:


<svg xmlns="http://www.w3.org/2000/svg" viewBox="0 0 691.3 201.8">
  ...
  <path id="text-path" d="M108.7 124.1c44.2 29 101 38.4 152 24.4 37.5-10.3 70.7-32.1 106.5-47.3 41.9-17.8 88.1-26.4 133.2-20.8 31.7 4 62.7 15.3 88.7 33.6"/>
  <text>
    <text>
      <textPath href="#text-path">Welcome Everyone!</textPath>
    </text>
  </text>
</svg>


Now, our text should appear on our path, but it won't be aligned properly. To center the text, we will need to give our path a length that is divisible by two, in our case let's just make it two. And we'll add a startOffset of one to our textPath element, which will now make it start in the center of the path:


<svg xmlns="http://www.w3.org/2000/svg" viewBox="0 0 691.3 201.8">
  ...
  <path id="text-path" pathLength="2" d="M108.7 124.1c44.2 29 101 38.4 152 24.4 37.5-10.3 70.7-32.1 106.5-47.3 41.9-17.8 88.1-26.4 133.2-20.8 31.7 4 62.7 15.3 88.7 33.6"/>
  <text>
    <text>
      <textPath href="#text-path" startOffset="1">Welcome Everyone!</textPath>
    </text>
  </text>
</svg>


At this point, it still isn't quite centered. So we can add a text-anchor style to properly align this.


textPath {
  text-anchor: middle;
}


There we go, now our text is properly centered. The final styles I added to my text are:


textPath {
  fill: #024949;
  font-size: 225%;
  font-weight: 700;
  letter-spacing: 0.02em;
  text-anchor: middle;
  text-shadow: 0 1px 0 rgba(255, 255, 255, 0.8);
}


And, when we resize our viewport, we can see that everything scales great. And what's great about this is that the text can be changed by simply editing the HTML. Of course, if we add too much text, it will break at some point, but it does have some flexibility. This method is not only visually appealing but also accessible and SEO-friendly, as the text is embedded in the document like any other text.

Conclusion

Using inline SVG and CSS, you can achieve some pretty neat stuff directly within your HTML without the need for images. The combination of accessibility, responsiveness, and SEO-friendliness makes this approach a valuable addition to your web design toolkit. Whether you're displaying messages, promotions, or information, this method offers a creative way to enhance your website's visual appeal in certain circumstances.

Want to See It in Action?

Check out the demo code and examples of these techniques, the code pen example below. If you have any questions or thoughts, don’t hesitate to leave a comment.
