ChipNeMo: Domain-Adapted LLMs for Chip Design: Dataset

Too Long; Didn't Read

Researchers present ChipNeMo, using domain adaptation to enhance LLMs for chip design, achieving up to 5x model size reduction with better performance.
featured image - ChipNeMo: Domain-Adapted LLMs for Chip Design: Dataset
Writings, Papers and Blogs on Text Models HackerNoon profile picture


(1) Mingjie Liu, NVIDIA {Equal contribution};

(2) Teodor-Dumitru Ene, NVIDIA {Equal contribution};

(3) Robert Kirby, NVIDIA {Equal contribution};

(4) Chris Cheng, NVIDIA {Equal contribution};

(5) Nathaniel Pinckney, NVIDIA {Equal contribution};

(6) Rongjian Liang, NVIDIA {Equal contribution};

(7) Jonah Alben, NVIDIA;

(8) Himyanshu Anand, NVIDIA;

(9) Sanmitra Banerjee, NVIDIA;

(10) Ismet Bayraktaroglu, NVIDIA;

(11) Bonita Bhaskaran, NVIDIA;

(12) Bryan Catanzaro, NVIDIA;

(13) Arjun Chaudhuri, NVIDIA;

(14) Sharon Clay, NVIDIA;

(15) Bill Dally, NVIDIA;

(16) Laura Dang, NVIDIA;

(17) Parikshit Deshpande, NVIDIA;

(18) Siddhanth Dhodhi, NVIDIA;

(19) Sameer Halepete, NVIDIA;

(20) Eric Hill, NVIDIA;

(21) Jiashang Hu, NVIDIA;

(22) Sumit Jain, NVIDIA;

(23) Brucek Khailany, NVIDIA;

(24) George Kokai, NVIDIA;

(25) Kishor Kunal, NVIDIA;

(26) Xiaowei Li, NVIDIA;

(27) Charley Lind, NVIDIA;

(28) Hao Liu, NVIDIA;

(29) Stuart Oberman, NVIDIA;

(30) Sujeet Omar, NVIDIA;

(31) Sreedhar Pratty, NVIDIA;

(23) Jonathan Raiman, NVIDIA;

(33) Ambar Sarkar, NVIDIA;

(34) Zhengjiang Shao, NVIDIA;

(35) Hanfei Sun, NVIDIA;

(36) Pratik P Suthar, NVIDIA;

(37) Varun Tej, NVIDIA;

(38) Walker Turner, NVIDIA;

(39) Kaizhe Xu, NVIDIA;

(40) Haoxing Ren, NVIDIA.


A. DAPT Dataset

During Domain-Adaptive Pre-Training (DAPT), we assemble a dataset from a combination of NVIDIA-proprietary chip design specific data sources and publicly available datasets.

Chip Design Datasets: Our internal dataset consists of a diverse range of text sources pertinent to chip design, spanning design, verification, infrastructure, and internal documentation. Table I provides a breakdown of the data collected after filtering, and the corresponding number of tokens using the LLaMA2 tokenizer. We construct the dataset by gathering all relevant internal data, then filtering by file type, based on filename extensions and distinguishing between machine-generated and human-written content. Although we evaluated on three specific use cases, we did not specifically limit the dataset to sources known to be relevant to these use cases since we believed that incorporating additional domain knowledge would improve performance. After collection, cleaning, and filtering, the internal data training corpus has 23.1 billion tokens. Further details of the data collection process are covered in Appendix A.

Public Datasets: We augment the chip design specific data with a sample of publicly available data from various sources, a common practice in the development of foundational large language models. Our approach was to reuse public training data from other language models, with the stipulation that it must be publicly accessible and compatible with open sourcing. These datasets exhibit a high degree of correlation with the pretraining data used in LLaMA2 [5], with the intention of preserving general knowledge and natural language capabilities during DAPT. The public datasets used by ChipNeMo can be categorized into two groups, natural language and code. For the natural language component, we draw from Wikipedia data [17], as it is widely regarded for its high data quality. For code, we leverage GitHub data [18], focusing on programming languages also present in our internal data chip design dataset such as C++, Python, and Verilog. To ensure that the overall dataset is representative of pre-training distributions, we perform a subsampling operation that results in approximately 9.2% of the total training tokens being sampled from these public datasets, with a balanced representation of natural language and code.

Data Blend: A significant proportion of the domain data we gathered is comprised of unannotated code from diverse origins. In an effort to enhance the model’s comprehension of domain-specific knowledge, we conducted downsampling of code data while concurrently upsampling natural language data, specifically design documentation, over a span of 2 to 4 training epochs. We also increased the representation of data that we deemed more pertinent to downstream applications, such as human-written EDA tool scripts. Furthermore, we incorporated publicly available domain data for 1 epoch. Details of the token distribution for training are shown in Table I.

B. SFT Instruction Data

During Supervised Fine-Tuning (SFT), we employ a general chat SFT instruction dataset that is accessible for commercial use. The dataset is comprised largely of publicly available instruction following datasets including OASST [19], FLAN [20], P3 [21] and a small amount of a broad domain proprietary dataset comprising various topics such as brainstorming, open-ended question answering, rewriting, summarization etc. It’s important to note that the SFT instruction data we discuss here is focused on general natural language tasks and does not contain any information or tasks related to the downstream use cases in chip design. In total, this dataset comprises 128,000 training samples.

Additionally, we meticulously assembled a domain-specific instruction dataset for aligning the model to downstream use cases. These examples have been meticulously crafted by subject matter experts and are formatted as single-turn questions and answers. Table II depicts the quantity of our domainspecific instruction dataset. It’s worth noting that the total number of training samples in the domain-specific instruction dataset is quite small when compared to the extensive amount of generative chat instruction data.

C. AutoEval

In order to quickly and quantitatively assess the accuracy of various models, we established evaluation criteria structured as multiple-choice question-and-answer formats for each use case, designed to closely align with established benchmarks, such as MMLU [22]. In the process of formulating these multiplechoice questions, collaboration with domain experts was pivotal. The goal was to ensure that each question included at least one complex answer choice, thereby posing a challenge to individuals with limited domain expertise. Careful attention was also given to prevent any inadvertent contamination of the questions with data from our domain-specific SFT. In addition to the per-use-case benchmarks, an additional benchmark was created for general circuit design knowledge, covering both analog and digital design topics. The number of multiple-choice questions for evaluation benchmark are shown in Table III.

When we report results on the above benchmarks, we take average results obtained from five distinct runs to mitigate the effects of variance and noise in the testing process. Each iteration employs a set of 5-shot examples, with variations introduced across each individual runs.

In addition to these domain-specific evaluation benchmarks, we also include commonly-used publicly available LLM academic benchmarks. Furthermore, we measure the model’s code generation capabilities, by evaluating HumanEval [23] for Python and VerilogEval [12] for Verilog.

This paper is available on arxiv under CC 4.0 license.
