CENTRAL SHAFT OF THE HOOSAC TUNNEL.

As many of our readers have evinced much interest and ingenuity on the question of the propriety of placing reliance upon the accuracy of dropping a perpendicular from the top to the bottom of a shaft 1,030 feet in depth, by means of an ordinary plummet, we take the earliest opportunity of settling the matter beyond dispute, by reporting the results lately obtained, through a series of experiments by the engineers in charge, for the ultimate purpose of laying down the correct line for the tunnel.

The perpendicular line has, of course, been dropped many times, and the main result taken. The plummet used is made of steel, properly balanced and polished, in shape something like a pineapple, and of about the same size, weighing fifteen pounds. It was suspended, with the large end downwards, by a thin copper wire, one fortieth of an inch in diameter, immersed in water; and, after careful steadying with the hand, occupied about an hour in assuming its final position or motion, which, contrary to the expectation and theories of many, resulted in a circular motion around a fixed point, the diameter of the circle being a mean of one quarter of an inch. The suspending wire in these operations was not quite the entire length of the shaft, being only 900 feet; and before the plummet had settled, the wire had stretched nearly twenty feet.

The suspension of the plummet in water was not considered necessary for any other reason than that water was continually trickling down the wire, and dropping on the plummet. The experiments so far have not been of the perfect character it is determined to attain, when the final alignment is made, as, until the headings east and west of the shaft have advanced to a considerable distance, any slight error would be of no account.

A neat and ingenious instrument has been constructed for determining the variation of the plummet, and will be used when great accuracy is desired; the plummet will also be suspended in oil.

The bearing of the tunnel is about S. 81° E.; but, independently of its near approach to the line of revolution described by the earth, it is not considered necessary to take into account any motion it may derive from this cause. In fact, the opinion is, that the motion of the earth will not practically have any effect.

On the whole, after the still imperfect experiments which have been made, enough is established to show there is no difficulty to be encountered, other than the accurate and delicate manipulation of the plummet and its attachments.

The shaft headings are progressing favorably. The rock is not so hard or varied as that met with at the west end markings. Already nearly 300 feet have been taken out, and with the proved energy of the contractors, this great task will doubtless be prosecuted steadily and surely to completion, within the contract time expiring March 1, 1874.
