I built an API with Go and PostgreSQL, set up a CI/CD pipeline with Google Cloud Run, Cloud Build, Secret Manager and Artifact Registry, and connected the Cloud Run instance to CockroachDB.
The API is based on the game Crisis Core: Final Fantasy VII, to simulate “Materia Fusion”. This article’s intended audience is for developers who just want to know how to build and deploy the API. I have another article where I talk about everything I learnt while working on this project and what didn’t work.
3 endpoints — health check (GET), list of all materia (GET), and simulate materia fusion (POST).
Materia (both singular and plural) is a crystal orb that serves as a source of magic. There are 144 distinct materia in the game, and they’re broadly classified into 4 categories: “Magic”, “Command”, “Support” and “Independent”. However, for the purpose of figuring out the rules of materia fusion, it was easier to have 32 internal categories based on their fusion behaviour, and 8 grades within those categories (see reference).
A materia becomes ‘Mastered’ when it is used for a certain duration. The duration is not important here.
Most importantly, 2 materia can be fused to produce a new materia. The rules governing fusion are influenced by:
X+Y
is not necessarily equal to Y+X
).
And there are a LOT of exceptions, with some rules having 3 levels of nested if-else
logic. This eliminates the possibility of creating a simple table in the DB and persisting 1000+ rules into it, or coming up with One Formula To Rule Them All.
In short, we need:
A table materia
with columns name(string)
, materia_type(ENUM)
(the 32 internal categories), grade(integer)
, display_materia_type(ENUM)
(the 4 categories used in the game), description(string)
and id(integer)
as an auto-incrementing primary key.
A data structure to encapsulate the basic rules format MateriaTypeA + MateriaTypeB = MateriaTypeC
.
Code to use the basic and complex rules to determine the output Materia in terms of its internal category and grade.
Ideally you can install the DB from the website itself. But the pgAdmin tool could not connect to the DB for some reason, so I used Homebrew.
brew install postgresql@17
This will install a whole bunch of CLI binary files to help use the DB.
Optional: add /opt/homebrew/opt/postgresql@17/bin
to $PATH
variable.
# create the DB
createdb materiafusiondb
# step into the DB to perform SQL commands
psql materiafusiondb
-- create an SQL user to be used by the Go server
CREATE USER go_client WITH PASSWORD 'xxxxxxxx';
-- The Go server doesn't ever need to add data to the DB.
-- So let's give it just read permission.
CREATE ROLE readonly_role;
GRANT USAGE ON SCHEMA public TO readonly_role;
-- This command gives SELECT access to all future created tables.
ALTER DEFAULT PRIVILEGES IN SCHEMA public GRANT SELECT ON TABLES TO readonly_role;
-- If you want to be more strict and give access only to tables that already exist, use this:
-- GRANT SELECT ON ALL TABLES IN SCHEMA public TO readonly_role;
GRANT readonly_role TO go_client;
CREATE TYPE display_materia_type AS ENUM ('Magic', 'Command', 'Support', 'Independent');
CREATE TYPE materia_type AS ENUM ('Fire', 'Ice', 'Lightning', 'Restore', 'Full Cure', 'Status Defense', 'Defense', 'Absorb Magic', 'Status Magic', 'Fire & Status', 'Ice & Status', 'Lightning & Status', 'Gravity', 'Ultimate', 'Quick Attack', 'Quick Attack & Status', 'Blade Arts', 'Blade Arts & Status', 'Fire Blade', 'Ice Blade', 'Lightning Blade', 'Absorb Blade', 'Item', 'Punch', 'SP Turbo', 'HP Up', 'AP Up', 'ATK Up', 'VIT Up', 'MAG Up', 'SPR Up', 'Dash', 'Dualcast', 'DMW', 'Libra', 'MP Up', 'Anything');
CREATE TABLE materia (
id integer NOT NULL,
name character varying(50) NOT NULL,
materia_type materia_type NOT NULL,
grade integer NOT NULL,
display_materia_type display_materia_type,
description text,
CONSTRAINT materia_pkey PRIMARY KEY (id)
);
-- The primary key 'id' should auto-increment by 1 for every row entry.CREATE SEQUENCE materia_id_seqAS integerSTART WITH 1INCREMENT BY 1NO MINVALUENO MAXVALUECACHE 1;
ALTER SEQUENCE materia_id_seq OWNED BY materia.id;
ALTER TABLE ONLY materia ALTER COLUMN id SET DEFAULT nextval('materia_id_seq'::REGCLASS);
Create an Excel sheet with table header and data, and export it as a CSV file. Then run the command:
COPY materia(name,materia_type,grade,display_materia_type,description) FROM
'<path_to_csv_file>/materiadata.csv' DELIMITER ',' CSV HEADER;
Create the boilerplate code using autostrada.dev. Add the options of api
, postgresql
, httprouter
, env var config
, tinted
logging, git
, live reload
, makefile
. We end up getting a file structure like this:
📦 codebase
├─ cmd
│ └─ api
│ ├─ errors.go
│ ├─ handlers.go
│ ├─ helpers.go
│ ├─ main.go
│ ├─ middleware.go
│ └─ server.go
├─ internal
│ ├─ database --- db.go
│ ├─ env --- env.go
│ ├─ request --- json.go
│ ├─ response --- json.go
│ └─ validator
│ ├─ helpers.go
│ └─ validators.go
├─ go.mod
├─ LICENSE
├─ Makefile
├─ README.md
└─ README.html
The boilerplate generator has created code to fetch environment variables and add them to the code, but we can make it easier to track and update the values.
Create <rootfolder>/.env
file. Add the following values:
HTTP_PORT=4444
DB_DSN=go_client:<password>@localhost:5432/materiafusiondb?sslmode=disable
API_TIMEOUT_SECONDS=5
API_CALLS_ALLOWED_PER_SECOND=1
Add the godotenv library:
go get github.com/joho/godotenv
Add the following to main.go
:
// At the beginning of main():
err := godotenv.Load(".env") // Loads environment variables from .env file
if err != nil { // This will be true in prod, but that's fine.
fmt.Println("Error loading .env file")
}
// Modify config struct:
type config struct {
baseURL string
db struct {
dsn string
}
httpPort int
apiTimeout int
apiCallsAllowedPerSecond float64
}
// Modify run() to use the new values from .env:
cfg.httpPort = env.GetInt("HTTP_PORT")
cfg.db.dsn = env.GetString("DB_DSN")
cfg.apiTimeout = env.GetInt("API_TIMEOUT_SECONDS")
cfg.apiCallsAllowedPerSecond = float64(env.GetInt("API_CALLS_ALLOWED_PER_SECOND"))
// cfg.baseURL = env.GetString("BASE_URL") - not required
The boilerplate already has a middleware to recover from panics. We will add 3 more: Content-Type checking, rate-limiting and API timeout protection.
Add tollbooth
library:
go get github.com/didip/tollbooth
Update <rootfolder/api/middleware.go
:
func (app *application) contentTypeCheck(next http.Handler) http.Handler {
return http.HandlerFunc(func(w http.ResponseWriter, r *http.Request) {
if r.Header.Get("Content-Type") != "application/json" {
app.unsupportedMediaType(w, r)
return
}
next.ServeHTTP(w, r)
})
}
func (app *application) rateLimiter(next http.Handler) http.Handler {
limiter := tollbooth.NewLimiter(app.config.apiCallsAllowedPerSecond, nil)
limiter.SetIPLookups([]string{"X-Real-IP", "X-Forwarded-For", "RemoteAddr"})
return tollbooth.LimitHandler(limiter, next)
}
func (app *application) apiTimeout(next http.Handler) http.Handler {
return http.HandlerFunc(func(w http.ResponseWriter, r *http.Request) {
timeoutDuration := time.Duration(app.config.apiTimeout) * time.Second
ctx, cancel := context.WithTimeout(r.Context(), timeoutDuration)
defer cancel()
r = r.WithContext(ctx)
done := make(chan struct{})
go func() {
next.ServeHTTP(w, r)
close(done)
}()
select {
case <-done:
return
case <-ctx.Done():
app.gatewayTimeout(w, r)
return
}
})
}
The middleware need to be added to the routes. They can be either added to all the routes, or to specific ones. In our case, Content-Type checking (that is, mandating the input headers to include Content-Type: application/json
) is only needed for POST requests. So modify routes.go
as follows:
func (app *application) routes() http.Handler {
mux := httprouter.New()
mux.NotFound = http.HandlerFunc(app.notFound)
mux.MethodNotAllowed = http.HandlerFunc(app.methodNotAllowed)
// Serve the Swagger UI. Uncomment this line later
// mux.Handler("GET", "/docs/*any", httpSwagger.WrapHandler)
mux.HandlerFunc("GET", "/status", app.status)
mux.HandlerFunc("GET", "/materia", app.getAllMateria)
// Adding content-type check middleware to only the POST method
mux.Handler("POST", "/fusion", app.contentTypeCheck(http.HandlerFunc(app.fuseMateria)))
return app.chainMiddlewares(mux)
}
func (app *application) chainMiddlewares(next http.Handler) http.Handler {
middlewares := []func(http.Handler) http.Handler{
app.recoverPanic,
app.apiTimeout,
app.rateLimiter,
}
for _, middleware := range middlewares {
next = middleware(next)
}
return next
}
Add the following methods to <rootfolder>/api/errors.go
to help the middleware functions:
func (app *application) unsupportedMediaType(w http.ResponseWriter, r *http.Request) {
message := fmt.Sprintf("The %s Content-Type is not supported", r.Header.Get("Content-Type"))
app.errorMessage(w, r, http.StatusUnsupportedMediaType, message, nil)
}
func (app *application) gatewayTimeout(w http.ResponseWriter, r *http.Request) {
message := "Request timed out"
app.errorMessage(w, r, http.StatusGatewayTimeout, message, nil)
}
<rootfolder>/api/dtos.go
:
package main
// MateriaDTO provides Materia details - Name, Description and Type (Magic / Command / Support / Independent)
type MateriaDTO struct {
Name string `json:"name" example:"Thunder"`
Type string `json:"type" example:"Magic"`
Description string `json:"description" example:"Shoots lightning forward dealing thunder damage."`}
// StatusDTO provides status of the server
type StatusDTO struct {
Status string `json:"Status" example:"OK"`
}
// ErrorResponseDTO provides Error message
type ErrorResponseDTO struct {
Error string `json:"Error" example:"The server encountered a problem and could not process your request"`
}
<rootfolder>/api/requests.go
:
package main
import (
"github.com/RayMathew/crisis-core-materia-fusion-api/internal/validator"
)
// MateriaFusionRequest provides input Materia names and their Mastered states
type MateriaFusionRequest struct {
Materia1Mastered *bool `json:"materia1mastered" example:"true"`
Materia2Mastered *bool `json:"materia2mastered" example:"false"`
Materia1Name string `json:"materia1name" example:"Fire"`
Materia2Name string `json:"materia2name" example:"Blizzard"`
Validator validator.Validator `json:"-"`
}
Validator
, from the generated code, will be used later to validate the input fields for \fusion
endpoint.
Create the file <rootfolder>/internal/crisis-core-materia-fusion/constants.go
. Add the following:
package crisiscoremateriafusion
type MateriaType string
const (
Fire MateriaType = "Fire"
Ice MateriaType = "Ice"
Lightning MateriaType = "Lightning"
Restore MateriaType = "Restore"
...
full list of 32 MateriaType
s can be found here.
Create the file <rootfolder>/internal/crisis-core-materia-fusion/models.go
. Add the following:
package crisiscoremateriafusion
type Materia struct {
Name string `json:"name"`
Type string `json:"materia_type"`
DisplayType string `json:"display_type"`
Description string `json:"description"`
Grade int `json:"grade"`
}
// Data structure to hold all basic combination rules
type BasicCombinationRule struct {
FirstMateriaType MateriaType
SecondMateriaType MateriaType
ResultantMateriaType MateriaType
}
var FILBasicRules = []BasicCombinationRule{
{Fire, Fire, Fire},
{Ice, Ice, Ice},
{Lightning, Lightning, Lightning},
{Fire, Ice, Lightning},
{Ice, Fire, Lightning},
{Fire, Lightning, Ice},
{Lightning, Fire, Ice},
{Lightning, Ice, Fire},
{Ice, Lightning, Fire},
}
var ...
full list of rules can be found here.
\materia
in api/handlers.go
func (app *application) getAllMateria(w http.ResponseWriter, r *http.Request) {
var allDisplayMateria []MateriaDTO
var allMateria []ccmf.Materia
var err error
allMateria, err = app.getAllMateriaFromApprSource()
if err != nil {
app.serverError(w, r, err)
}
// Some materia have the same name but different grades.
// We need to allow only unique names are sent in the response.
seenMateriaNames := make(map[string]bool)
for _, materia := range allMateria {
if _, isDuplicate := seenMateriaNames[materia.Name]; !isDuplicate {
seenMateriaNames[materia.Name] = true
allDisplayMateria = append(allDisplayMateria, MateriaDTO{
Name: materia.Name,
Type: materia.DisplayType,
Description: materia.Description,
})
}
}
err = response.JSON(w, http.StatusOK, allDisplayMateria)
if err != nil {
app.serverError(w, r, err)
}
}
func (app *application) getAllMateriaFromApprSource() (allMateria []ccmf.Materia, err error) {
// Check if allMateria data is in cache
if data, found := app.getCachedData(string(ccmf.AllMateriaCacheKey)); found {
// Type assertion: assert that data is of type []Materia
if allMateriaCache, ok := data.([]ccmf.Materia); ok {
allMateria = allMateriaCache
app.logger.Debug("cache hit")
} else {
app.logger.Error("Failed to assert cached data as []Materia")
return nil, errors.New("failed to assert cached data as []Materia")
}
} else {
// allMateria data is not in cache. Get from DB
app.logger.Debug("cache miss")
allMateria, err = app.db.GetAllMateria()
app.setCache(string(ccmf.AllMateriaCacheKey), allMateria)
}
return
}
We are using an in-server cache because:
\materia
and \fusion
endpoints.
Update main.go
:
// declare a cache and a mutex.
// the mutex is to ensure there is only one operation using the cache at a time.
type application struct {
db *database.DB
logger *slog.Logger
cache map[string]interface{}
wg sync.WaitGroup
mu sync.Mutex
config config
}
// in run() initialize the cache:
app := &application{
config: cfg,
db: db,
logger: logger,
cache: make(map[string]interface{}),
}
Update api/helpers.go
:
// remove backgroundTask()
// add getter and setter for the cache:
func (app *application) getCachedData(key string) (interface{}, bool) {
app.mu.Lock()
defer app.mu.Unlock()
data, found := app.cache[key]
return data, found
}
func (app *application) setCache(key string, value interface{}) {
app.mu.Lock()
defer app.mu.Unlock()
app.cache[key] = value
}
\fusion
in api/handlers.go
// showing only relevant parts of the code
func (app *application) fuseMateria(w http.ResponseWriter, r *http.Request) {
var fusionReq MateriaFusionRequest
err := request.DecodeJSON(w, r, &fusionReq)
if err != nil {
app.badRequest(w, r, err)
return
}
// Using the Validator we had defined in dtos.go
fusionReq.Validator.CheckField(fusionReq.Materia1Name != "", "materia1name", "materia1name is required")
fusionReq.Validator.CheckField(fusionReq.Materia2Name != "", "materia2name", "materia2name is required")
fusionReq.Validator.CheckField(fusionReq.Materia1Mastered != nil, "materia1mastered", "materia1mastered is required")
fusionReq.Validator.CheckField(fusionReq.Materia2Mastered != nil, "materia2mastered", "materia2mastered is required")
if fusionReq.Validator.HasErrors() {
app.failedValidation(w, r, fusionReq.Validator)
return
}
var allMateria []ccmf.Materia
allMateria, err = app.getAllMateriaFromApprSource()
if err != nil {
app.serverError(w, r, err)
}
var materia1Type string
var materia1Grade int
var materia2Type string
var materia2Grade int
// matching the request input with the categories in DB
for _, materia := range allMateria {
if materia1Type != "" && materia2Type != "" {
break
}
if materia.Name == fusionReq.Materia1Name && materia1Type == "" {
materia1Type = materia.Type
materia1Grade = materia.Grade
}
if materia.Name == fusionReq.Materia2Name && materia2Type == "" {
materia2Type = materia.Type
materia2Grade = materia.Grade
}
}
if materia1Type == "" || materia2Type == "" {
app.badRequest(w, r, errors.New("one or both of the Materia names are not recognised"))
return
}
// game rule - higher grade Materia moves to first position
exchangePositionsIfNeeded(&fusionReq, &materia1Grade, &materia2Grade, &materia1Type, &materia2Type)
relevantBasicRuleMap := ccmf.BasicRuleMap[ccmf.MateriaType(materia1Type)]
var relevantBasicRule ccmf.BasicCombinationRule
// finding the relevant combination rule
for _, rule := range relevantBasicRuleMap {
if (rule.FirstMateriaType == ccmf.MateriaType(materia1Type)) &&
(rule.SecondMateriaType == ccmf.MateriaType(materia2Type)) {
relevantBasicRule = rule
break
}
}
var resultantMateria MateriaDTO
// game rule - grade of resultant Materia depends on the input Materia as well as their Mastered state
resultantMateriaGrade := determineGrade(fusionReq, materia1Grade)
if relevantBasicRule.FirstMateriaType == "" {
app.logger.Info("none of the basic rules satisfy the requirement.")
// get final output using complex rules
resultantMateria = useComplexRules(materia1Grade, materia2Grade, resultantMateriaGrade, materia1Type, materia2Type, *fusionReq.Materia1Mastered, *fusionReq.Materia2Mastered, &allMateria)
} else {
// get final output using basic rules
resultantMateriaType := relevantBasicRule.ResultantMateriaType
for _, materia := range allMateria {
if materia.Grade == resultantMateriaGrade && materia.Type == string(resultantMateriaType) {
resultantMateria.Name = materia.Name
resultantMateria.Type = materia.DisplayType
resultantMateria.Description = materia.Descriptionbreak
}
}
}
err = response.JSON(w, http.StatusOK, resultantMateria)
if err != nil {
app.serverError(w, r, err)
}
}
// Combination rules which do not follow any pattern, and had to be coded separately
func useComplexRules(materia1Grade, materia2Grade, resultantMateriaGrade int, materia1Type, materia2Type string, materia1Mastered, materia2Mastered bool, allMateria *[]ccmf.Materia) (resultantMateria MateriaDTO) {
var resultantMateriaType string
switch {
// Complex Rule 1: FIL, Defense
case (materia1Type == string(ccmf.Fire) ||
materia1Type == string(ccmf.Ice) ||
materia1Type == string(ccmf.Lightning)) && materia2Type == string(ccmf.Defense):
if materia1Grade == 1 && materia2Grade == 1 {
// output is Defense when grades are equal to 1
resultantMateriaType = string(ccmf.Defense)
if materia1Mastered || materia2Mastered {
// final Grade is increased when output is Defense
increaseGrade(&resultantMateriaGrade)
}
} else {
// output is FIL when grades are NOT equal to 1
resultantMateriaType = materia1Type
}
...
// prepare response DTO
updateResultantMateriaData(allMateria, resultantMateriaGrade, resultantMateriaType, &resultantMateria)
return resultantMateria
}
Complete handler code can be found here.
Add the Swagger library:
go get -u github.com/swaggo/swag/cmd/swag
go get github.com/swaggo/http-swagger
go get github.com/swaggo/swag
In routes.go
uncomment the Swagger line, and add the import:
httpSwagger "github.com/swaggo/http-swagger"
In the handler, DTO and model files, add comments for Swagger documentation. Refer this for all options.
In the terminal, run:
cd api
swag init -d .
This creates an api/docs
folder, with the definition available for Go, JSON and YAML.
To test it, start the local server and open [http://localhost:4444/docs](http://localhost:4444/docs)
.
Final folder structure:
📦 crisis-core-materia-fusion-api
.gitignore
├─ Dockerfile
├─ LICENSE
├─ Makefile
├─ README.md
├─ api
│ ├─ docs
│ │ ├─ docs.go
│ │ ├─ swagger.json
│ │ └─ swagger.yaml
│ ├─ dtos.go
│ ├─ errors.go
│ ├─ handlers.go
│ ├─ helpers.go
│ ├─ main.go
│ ├─ middleware.go
│ ├─ requests.go
│ ├─ routes.go
│ └─ server.go
├─ go.mod
├─ go.sum
└─ internal
├─ crisis-core-materia-fusion
│ ├─ constants.go
│ └─ models.go
├─ database -- db.go
├─ env -- env.go
├─ request -- json.go
├─ response -- json.go
└─ validator
├─ helpers.go
└─ validator.go
<rootfolder>/certs/root.crt
in the project and add the certificate there. We will make a reference to this file later in the Google Run configuration.certs/
folder to .gitignore
. We are creating the certificate in local only to test the connection, if you wish.From your local DB instance, run:
pg_dump --no-owner --no-privileges -U <admin_username> -d materiafusiondb > full_dump.sql
IMPORT INTO
. So I had to create an INSERT
statement in a local SQL file for 270 rows (which we can derive from the pg_dump
output we just got).
Logging in to the remote instance:
psql -h <REMOTE_DB_CLUSTER_HOSTNAME> -U <REMOTE_USERNAME> -d materiafusiondb -p <REMOTE_DB_PORT>
.env
file.
Values:
<remote_cockroachdb_url>?sslmode=verify-full&sslrootcert=/app/certs/root.crt
The last piece of the puzzle.
.crt
certificate of the CockroachDB.
- name: 'gcr.io/google.com/cloudsdktool/cloud-sdk:slim'
args:
- '-c'
- >
mkdir -p certs
gcloud secrets versions access latest --secret="DB_CERT" >
certs/root.crt
id: Fetch Secret
This will make Cloud Build create the file certs/root.crt
in our project before the build starts, so that the Dockerfile will have access to it even though we never pushed it to our Github repository.
And that’s it. Try pushing a commit and check if the build triggers. The Cloud Run dashboard will show the URL of your hosted Go server.
For questions related to “Why did you do X and not Y?” read this.
For anything else that you want to know or discuss, go here.
