Apache NiFi is a powerful tool for automating data flows with a large number of built-in processors. However, sometimes there is a need for specific processors to handle unique requirements and data stores. In such cases, creating custom processors becomes a necessity. In this article, we will go through the steps to create a very simple custom processor for Apache NiFi. Setup and sources gradle setup dependencies {
	compile "org.apache.nifi:nifi-api:*"
	compile "org.apache.nifi:nifi-utils:1.9.2"
	testCompile "org.apache.nifi:nifi-mock:1.9.2"
} source of the custom processor import org.apache.nifi.annotation.behavior.ReadsAttribute;
import org.apache.nifi.annotation.behavior.ReadsAttributes;
import org.apache.nifi.annotation.behavior.WritesAttribute;
import org.apache.nifi.annotation.behavior.WritesAttributes;
import org.apache.nifi.annotation.documentation.CapabilityDescription;
import org.apache.nifi.annotation.documentation.SeeAlso;
import org.apache.nifi.annotation.documentation.Tags;
import org.apache.nifi.annotation.lifecycle.OnScheduled;
import org.apache.nifi.components.PropertyDescriptor;
import org.apache.nifi.expression.ExpressionLanguageScope;
import org.apache.nifi.flowfile.FlowFile;
import org.apache.nifi.processor.*;
import org.apache.nifi.processor.exception.ProcessException;
import org.apache.nifi.processor.util.StandardValidators;

import java.io.OutputStream;
import java.nio.charset.StandardCharsets;
import java.util.*;

@Tags({"example"})
@CapabilityDescription("Hello World to output")
@SeeAlso({})
@ReadsAttributes({@ReadsAttribute(attribute = "", description = "")})
@WritesAttributes({@WritesAttribute(attribute = "", description = "")})
public class MyProcessor extends AbstractProcessor {

    public static final PropertyDescriptor propertyDescriptor = new PropertyDescriptor
            .Builder().name("name")
            .displayName("name")
            .description("Name to print")
            .required(true)
            .addValidator(StandardValidators.NON_EMPTY_VALIDATOR)
            .expressionLanguageSupported(ExpressionLanguageScope.FLOWFILE_ATTRIBUTES)
            .build();

    public static final Relationship successRelations = new Relationship.Builder()
            .name("success")
            .description("If everything is ok")
            .build();

    public static final Relationship failureRelations = new Relationship.Builder()
            .name("failure")
            .description("If something is wrong")
            .build();

    private List<PropertyDescriptor> descriptorList;

    private Set<Relationship> relationshipSet;

    @Override
    protected void init(final ProcessorInitializationContext context) {
        final List<PropertyDescriptor> descriptors = new ArrayList<PropertyDescriptor>();
        descriptors.add(propertyDescriptor);
        this.descriptorList = Collections.unmodifiableList(descriptors);

        final Set<Relationship> relationships = new HashSet<Relationship>();
        relationships.add(successRelations);
        relationships.add(failureRelations);
        this.relationshipSet = Collections.unmodifiableSet(relationships);
    }

    public Set<Relationship> getRelationshipSet() {
        return this.relationshipSet;
    }

    @Override
    public final List<PropertyDescriptor> getSupportedPropertyDescriptors() {
        return descriptorList;
    }

    @OnScheduled
    public void onScheduled(final ProcessContext context) {

    }

    @Override
    public void onTrigger(final ProcessContext context, final ProcessSession session) throws ProcessException {
        FlowFile flowFile = session.get();
        if (flowFile == null) {
            return;
        }

        try {
            String name = context.getProperty(propertyDescriptor).evaluateAttributeExpressions(flowFile).getValue();

            String result = "Hello " + name;
            session.putAttribute(flowFile, "result", result);

            try (OutputStream flowFileOutputStream = session.write(flowFile)) {
                flowFileOutputStream.write(result.getBytes(StandardCharsets.UTF_8));
            }

            session.transfer(flowFile, successRelations);
        } catch (IOException e) {
		        //IO Error processing error log
		        session.transfer(flowFile, failureRelations);
		    } catch (ProcessException e) {
				    // Process error log
		        getLogger().error("Processing error", e);
		        session.transfer(flowFile, failureRelations);
		    }
    }
} Build and deploy Build the project with Gradle: gradle build.
Find the generated .nar file in the target folder of your module.
Copy the .nar file to the lib folder of your NiFi installation. Screenshot of how the custom processor integrates seamlessly I hope this article was useful for you! Creating a custom processor for Apache NiFi allows you to customize it to meet the specific requirements of your project. By following the steps above, you will be able to develop and integrate a custom processor that will enhance the processing capabilities of your system. Apache NiFi is a powerful tool for automating data flows with a large number of built-in processors. However, sometimes there is a need for specific processors to handle unique requirements and data stores. In such cases, creating custom processors becomes a necessity. In this article, we will go through the steps to create a very simple custom processor for Apache NiFi. Setup and sources gradle setup gradle setup dependencies {
	compile "org.apache.nifi:nifi-api:*"
	compile "org.apache.nifi:nifi-utils:1.9.2"
	testCompile "org.apache.nifi:nifi-mock:1.9.2"
} dependencies {
	compile "org.apache.nifi:nifi-api:*"
	compile "org.apache.nifi:nifi-utils:1.9.2"
	testCompile "org.apache.nifi:nifi-mock:1.9.2"
} source of the custom processor source of the custom processor import org.apache.nifi.annotation.behavior.ReadsAttribute;
import org.apache.nifi.annotation.behavior.ReadsAttributes;
import org.apache.nifi.annotation.behavior.WritesAttribute;
import org.apache.nifi.annotation.behavior.WritesAttributes;
import org.apache.nifi.annotation.documentation.CapabilityDescription;
import org.apache.nifi.annotation.documentation.SeeAlso;
import org.apache.nifi.annotation.documentation.Tags;
import org.apache.nifi.annotation.lifecycle.OnScheduled;
import org.apache.nifi.components.PropertyDescriptor;
import org.apache.nifi.expression.ExpressionLanguageScope;
import org.apache.nifi.flowfile.FlowFile;
import org.apache.nifi.processor.*;
import org.apache.nifi.processor.exception.ProcessException;
import org.apache.nifi.processor.util.StandardValidators;

import java.io.OutputStream;
import java.nio.charset.StandardCharsets;
import java.util.*;

@Tags({"example"})
@CapabilityDescription("Hello World to output")
@SeeAlso({})
@ReadsAttributes({@ReadsAttribute(attribute = "", description = "")})
@WritesAttributes({@WritesAttribute(attribute = "", description = "")})
public class MyProcessor extends AbstractProcessor {

    public static final PropertyDescriptor propertyDescriptor = new PropertyDescriptor
            .Builder().name("name")
            .displayName("name")
            .description("Name to print")
            .required(true)
            .addValidator(StandardValidators.NON_EMPTY_VALIDATOR)
            .expressionLanguageSupported(ExpressionLanguageScope.FLOWFILE_ATTRIBUTES)
            .build();

    public static final Relationship successRelations = new Relationship.Builder()
            .name("success")
            .description("If everything is ok")
            .build();

    public static final Relationship failureRelations = new Relationship.Builder()
            .name("failure")
            .description("If something is wrong")
            .build();

    private List<PropertyDescriptor> descriptorList;

    private Set<Relationship> relationshipSet;

    @Override
    protected void init(final ProcessorInitializationContext context) {
        final List<PropertyDescriptor> descriptors = new ArrayList<PropertyDescriptor>();
        descriptors.add(propertyDescriptor);
        this.descriptorList = Collections.unmodifiableList(descriptors);

        final Set<Relationship> relationships = new HashSet<Relationship>();
        relationships.add(successRelations);
        relationships.add(failureRelations);
        this.relationshipSet = Collections.unmodifiableSet(relationships);
    }

    public Set<Relationship> getRelationshipSet() {
        return this.relationshipSet;
    }

    @Override
    public final List<PropertyDescriptor> getSupportedPropertyDescriptors() {
        return descriptorList;
    }

    @OnScheduled
    public void onScheduled(final ProcessContext context) {

    }

    @Override
    public void onTrigger(final ProcessContext context, final ProcessSession session) throws ProcessException {
        FlowFile flowFile = session.get();
        if (flowFile == null) {
            return;
        }

        try {
            String name = context.getProperty(propertyDescriptor).evaluateAttributeExpressions(flowFile).getValue();

            String result = "Hello " + name;
            session.putAttribute(flowFile, "result", result);

            try (OutputStream flowFileOutputStream = session.write(flowFile)) {
                flowFileOutputStream.write(result.getBytes(StandardCharsets.UTF_8));
            }

            session.transfer(flowFile, successRelations);
        } catch (IOException e) {
		        //IO Error processing error log
		        session.transfer(flowFile, failureRelations);
		    } catch (ProcessException e) {
				    // Process error log
		        getLogger().error("Processing error", e);
		        session.transfer(flowFile, failureRelations);
		    }
    }
} import org.apache.nifi.annotation.behavior.ReadsAttribute;
import org.apache.nifi.annotation.behavior.ReadsAttributes;
import org.apache.nifi.annotation.behavior.WritesAttribute;
import org.apache.nifi.annotation.behavior.WritesAttributes;
import org.apache.nifi.annotation.documentation.CapabilityDescription;
import org.apache.nifi.annotation.documentation.SeeAlso;
import org.apache.nifi.annotation.documentation.Tags;
import org.apache.nifi.annotation.lifecycle.OnScheduled;
import org.apache.nifi.components.PropertyDescriptor;
import org.apache.nifi.expression.ExpressionLanguageScope;
import org.apache.nifi.flowfile.FlowFile;
import org.apache.nifi.processor.*;
import org.apache.nifi.processor.exception.ProcessException;
import org.apache.nifi.processor.util.StandardValidators;

import java.io.OutputStream;
import java.nio.charset.StandardCharsets;
import java.util.*;

@Tags({"example"})
@CapabilityDescription("Hello World to output")
@SeeAlso({})
@ReadsAttributes({@ReadsAttribute(attribute = "", description = "")})
@WritesAttributes({@WritesAttribute(attribute = "", description = "")})
public class MyProcessor extends AbstractProcessor {

    public static final PropertyDescriptor propertyDescriptor = new PropertyDescriptor
            .Builder().name("name")
            .displayName("name")
            .description("Name to print")
            .required(true)
            .addValidator(StandardValidators.NON_EMPTY_VALIDATOR)
            .expressionLanguageSupported(ExpressionLanguageScope.FLOWFILE_ATTRIBUTES)
            .build();

    public static final Relationship successRelations = new Relationship.Builder()
            .name("success")
            .description("If everything is ok")
            .build();

    public static final Relationship failureRelations = new Relationship.Builder()
            .name("failure")
            .description("If something is wrong")
            .build();

    private List<PropertyDescriptor> descriptorList;

    private Set<Relationship> relationshipSet;

    @Override
    protected void init(final ProcessorInitializationContext context) {
        final List<PropertyDescriptor> descriptors = new ArrayList<PropertyDescriptor>();
        descriptors.add(propertyDescriptor);
        this.descriptorList = Collections.unmodifiableList(descriptors);

        final Set<Relationship> relationships = new HashSet<Relationship>();
        relationships.add(successRelations);
        relationships.add(failureRelations);
        this.relationshipSet = Collections.unmodifiableSet(relationships);
    }

    public Set<Relationship> getRelationshipSet() {
        return this.relationshipSet;
    }

    @Override
    public final List<PropertyDescriptor> getSupportedPropertyDescriptors() {
        return descriptorList;
    }

    @OnScheduled
    public void onScheduled(final ProcessContext context) {

    }

    @Override
    public void onTrigger(final ProcessContext context, final ProcessSession session) throws ProcessException {
        FlowFile flowFile = session.get();
        if (flowFile == null) {
            return;
        }

        try {
            String name = context.getProperty(propertyDescriptor).evaluateAttributeExpressions(flowFile).getValue();

            String result = "Hello " + name;
            session.putAttribute(flowFile, "result", result);

            try (OutputStream flowFileOutputStream = session.write(flowFile)) {
                flowFileOutputStream.write(result.getBytes(StandardCharsets.UTF_8));
            }

            session.transfer(flowFile, successRelations);
        } catch (IOException e) {
		        //IO Error processing error log
		        session.transfer(flowFile, failureRelations);
		    } catch (ProcessException e) {
				    // Process error log
		        getLogger().error("Processing error", e);
		        session.transfer(flowFile, failureRelations);
		    }
    }
} Build and deploy Build and deploy Build the project with Gradle: gradle build. Find the generated .nar file in the target folder of your module. Copy the .nar file to the lib folder of your NiFi installation. Build the project with Gradle: gradle build . gradle build Find the generated .nar file in the target folder of your module. .nar Copy the .nar file to the lib folder of your NiFi installation. .nar lib Screenshot of how the custom processor integrates seamlessly Screenshot of how the custom processor integrates seamlessly I hope this article was useful for you! Creating a custom processor for Apache NiFi allows you to customize it to meet the specific requirements of your project. By following the steps above, you will be able to develop and integrate a custom processor that will enhance the processing capabilities of your system.

The code in this story is for educational purposes. The readers are solely responsible for whatever they build with it.

Walkthroughs, tutorials, guides, and tips. This story will teach you how to do something new or how to do something better.

Building a Simple Custom Processor With Apache Ni-Fi

About Author

Comments

TOPICS

THIS ARTICLE WAS FEATURED IN

Related Stories

ClickHouse DateTime Parsing: Should You Use 'Base' or 'Best_effort' Mode?

Setting up Data Streams Using NiPyAPI: UI-Free Guide

Is Your Apache Ni-Fi Ready for Production?

Kerberos + Ni-Fi = Secure

DolphinScheduler and SeaTunnel VS. AirFlow and NiFi

Data Warehouse vs Data Lake

ClickHouse DateTime Parsing: Should You Use 'Base' or 'Best_effort' Mode?

Setting up Data Streams Using NiPyAPI: UI-Free Guide

Is Your Apache Ni-Fi Ready for Production?

Kerberos + Ni-Fi = Secure

DolphinScheduler and SeaTunnel VS. AirFlow and NiFi

Data Warehouse vs Data Lake

Light-Mode

Classic

Newspaper

Minty

Dark-Mode

Neon Noir

Minty

HN StartUps
