A Tale of JavaScript Performance, Part 3 This article continues my series chronicling my investigation into performance by creating , a visualization tool for Chrome memory profiles. Today I will be taking a deep dive into my creation of the renderer. If you missed it, check out and . JavaScript HeapViz part 1 part 2 Starting with D3 and SVG With my and , the time had come to get down to it and actually draw some nodes. file format parsed my visualization method chosen To learn how to actually implement a circle-packing layout, I started by going over some helpful tutorials. I read up on , and found a couple of on . It didn’t take long before I had a rudimentary renderer churning out SVGs from a dummy heap profile. It looked like this: d3-heirarchy’s pack layout excellent examples bl.ocks.org This was my first attempt, and it worked! I was able to draw this of a small sample of my test profile: visualization Output of a small sample on the SVG renderer It looks like we have accomplished a few of our goals! We can clearly identify the outlier nodes, we get a quick feel for what distribution of the major node types are, and we can easily see which nodes are retaining a lot of memory. The scheme might need a little work, but for a first pass this seems like a simple and robust solution. color With the proof of concept working well on a small sample, I decided to throw it against my upper bound — a profile from an app at work that contains a meager 1,050,000 nodes. Predictably, it blew the tab’s ~4GB memory limit in just a couple of minutes, locking up the browser. It didn’t take long to reason through why — the snippet above renders 4 DOM nodes per heap node, including a relatively weighty and . A browser might be able to handle a million empty s, but there is no way it can handle a million paths in an SVG. Playing around with the renderer lead to an upper limit of around 10,000 nodes on my MacBook Pro. <circle> <clipPath> <div> Do we really need to render everything? In order to achieve the goal of making a tool useful enough to debug issues with most memory profiles, an intelligent filtering algorithm that displayed the largest nodes along with some useful metadata probably be just fine. I’d wager that even with a view of as few as 100 nodes at a time would be more than sufficient for highlighting any problem areas. Here’s the issue: I didn’t want to build that tool. I wanted to build a tool for visualizing an heap profile, not just the subset that I assumed was most useful for my users. Furthermore, I was really intrigued by the challenge. What and techniques could I use for rendering a full two orders of magnitude more nodes? entire tools I decided to see what I could do to squeeze every last drop of juice out of a renderer and take on the million node challenge. Take 2: PixiJS with Vectors SVG is clearly not memory efficient enough as an output format, so I would need to use one of the web’s other options — either a standard or . WebGL gives me the finest-grain control over the memory footprint of my renderer, so it was a natural first choice. I chose the framework because it was optimized around efficient 2D rendering. canvas 2D drawing context WebGL PixiJS Here’s how the renderer in Pixi looks: There is a little magic being done behind the scenes by , but for the most part the rendering is straightforward. I did run into a couple of challenges: ember-cli-pixijs Antialiasing. Even with antialiasing enabled in the renderer, I ended up needing to 2x my resolution and compress the image using a CSS transform in order to get relatively crisp edges. UI lock during rendering. In the snippet above, you can see that we batch our draws with a somewhat arbitrary batch size of 5,000 nodes. This allows for a pretty nifty progressive draw effect but does slow down our render. With this renderer, I was able to get to around 50,000 nodes without issue: We’re moving in the right direction, but 50k is still a long ways from 1 million. Switching to vector-based WebGL got us a 5x nodes rendered improvement, but ultimately it was not able to break through the 100k, let alone 1 million barrier. After hitting the books once more, I found my major issue. I was misusing the PixiJS library! It was created as the renderer for the game engine, and while it draw vectors, it has been optimized around drawing sprites. To use it to its full potential, I needed to convert my circles to rasterized textures. Phaser can Next Attempt: PixiJS with Textures My strategy for rasterizing my circles was simple — create a texture for each node type by drawing a large circle in each color of the color scale I was using, and then reference that texture by node type when drawing the node. Here’s what I added: One “gotcha” in this code is that we need to generate our basic textures as a power of 2. This is a of WebGL that will cause degraded performance if violated. well-documented property Here’s the output with the sprite-based renderer: Boom! 1 mill… wait, no, that’s still only 220,000 nodes. And it took nearly 10 minutes to render. Pretty dang good, but still not good enough. Edit: /u/grinde pointed out that I should have used a ParticleContainer instead of a normal PIXI.Container to render my sprites as it is optimized for rendering tons of simple sprites. I will do some benchmarks and report how it stacks up (hah) against stackgl Extra Credit: stackgl Recently, I stumbled on this of all of the major WebGL frameworks. PixiJS holds up fairly well at the high end, but there is one hands-down favorite: . spectacularly helpful benchmark stackgl Stackgl isn’t so much a WebGL framework as a collection of composable utilities that make it easier to assemble shaders. While all of the other frameworks have robust primitive support, stackgl makes you roll your own — but the obvious upshot is screaming performance. Even though at this point my rendering speed was far outpacing my other bottlenecks, I thought it was worth it to give stackgl a shot for three reasons: Large profile renders were still taking a significant amount of time. Object picking with the mouse (i.e. which node am I hovering) was really slow on large profiles with Pixi. It would get me closer to the GPU, giving me some valuable experience writing shaders. Thankfully, there is a of using stackgl to render primitives. I was able to leverage that to build the following: good example This iteration of the renderer proved to be almost 3x faster than the previous, and opened up a lot of doors for optimization around interaction. I finally had a renderer that would hold up to the largest profiles I could throw at it! So, if my bottleneck was no longer the renderer, what was it? Find out next time! Up next — Part 4: Working with Workers for a Jank-Free UI
