3.2. Likely terraformed planets can be identified from clustering

We next attempted to select planets with high potential for having undergone terraformation. Based on the idea that terraformed planets are likely to have similar compositions, we start by clustering planets based on only their compositions, at each simulation iteration (see Methods 2.2.3). The key question is—of the clusters identified, which ones likely contain terraformed planets? To address this, we selected clusters (without using the ground truth labels of which planets were terraformed) by looking at the effect they have, when removed, on the residual space’s Mantel coefficient (Mantel contribution > 0; Fig. 3). We further selected clusters based on their planets’ spatial localization (IQR ≤ 25.2; Fig. 4).


Figure 3. Mantel contribution as a cluster selection criterion. Clusters with a Mantel contribution > 0 (black) meet this selection criterion, indicating that their removal is a detriment to the residual space’s Mantel coefficient (causing it to decrease). Clusters with a negative Mantel contribution shown in grey. The inset shows the full range of negative values in all clusters.


With both of these selection criteria applied, we detect a total of 247 clusters across all terraformed ratios—the earliest first appearing at a terraformed ratio of 0.04 (Figs. 5, 6). Selected clusters range in size depending on the terraformed ratio, with 1-3 clusters appearing at most simulation iterations between terraformed ratios of 0.04 to 1. Additionally, we find that the Mantel pvalue of detected clusters, measured in isolation, is low


Figure 4. Selection criteria used on clusters of planets. Spatial localization of clusters of planets is shown on the yaxis, as measured by the Interquartile Range (IQR) of each cluster. Horizontal dashed line (at IQR = 25.2) denotes the threshold used, below which we selected clusters for being spatially localized. This corresponds to approximately the average IQR of planets in a cube the size of 1/8 the model space. Color bar shows the Mantel Contribution (MC) of clusters, with a high MC indicating a cluster as being important for raising the full space’s Mantel coefficient.


(Fig. A5). Changing the parameters used in clustering, or the thresholds used for IQR and MC could identify planet clusters either earlier (by increasing sensitivity) or later (by increasing the IQR threshold).


After selecting clusters, we evaluate if they actually contain terraformed planets (Figs. 7, 8). We find that across the full range of terraformed ratios, they have extremely high specificity—close to 1.0—correctly rejecting non-terraformed planets as being nonterraformed. On the other hand, detected cluster sensitivity—a measure of correctly detecting terraformed planets as being terraformed—ranges from 1.0, down to near 0.0. Perhaps surprisingly, but encouragingly, the highest sensitivity clusters appear when fewer planets are terraformed. This is could be explained by the fact that throughout the simulation clusters remain small (in terms of number of planets), and the rest of the planets often get classified as noise (this being due to the sensitivity to elbow selection). As a consequence of decreasing sensitivity, accuracy—the proportion of all planets correctly classified—also decreases.


When we raise the MC threshold used for cluster selection (to 0.25 or 0.5), we find that each of these summary statistics improves, reflecting the fact that the more the MC threshold is raised, the more data is excluded from higher terraformed ratios, meaning that the bulk of the


Figure 5. The earliest detected cluster in our simulation, at a terraformed ratio of 0.04. This is a projection of 3D planet locations in the 2D X-Y plane, and the earliest timestep where we detect a cluster of planets meeting our selection criteria. True terraformed planets (n = 40) have blue fill, while planets detected by our selection method (n = 19) have a red outline.


Figure 6. PCA of planetary compositions at a terraformed ratio of 0.04, the earliest time step where we detect selected clusters (red). PCA is used here only for displaying 10 compositional dimensions on a 2D page, and was not used for clustering.


data remaining is from early clusters with high sensitivity and high accuracy (Figs. 7, 8).


Authors:

(1) Harrison B. Smith, Earth-Life Science Institute, Tokyo Institute of Technology, Ookayama, Meguro-ku, Tokyo, Japan, and Blue Marble Space Institute of Science, Seattle, Washington, USA ([email protected]);

(2) Lana Sinapayen, Sony Computer Science Laboratories, Kyoto, Japan and National Institute for Basic Biology, Okazaki, Japan ([email protected]).


This paper is available on arxiv under CC BY-NC-ND 4.0 Deed license.
