NEW MECHANICAL AND ENGINEERING INVENTIONS.

IMPROVED COTTON GIN.

Joseph W. Thorn, Iuka, Miss., assignor to himself and M.W. Beardsley, of same place.—In this machine there is a new construction of the brush drum for simplifying the same, and facilitating the application of the brush wings, so that they can be readily taken off and put on; also, an arrangement of the ribs between the saws for facilitating the separating of the seed from the cotton without breaking and injuring the fiber. There are also ingenious devices for preventing the seed from gathering and clogging at the ends of the saw drum.

IMPROVED SAFETY CHECK FOR ELEVATORS.

Nathan H. Fogg, Boston, Mass.—When the car is suspended normally from the rope, the rubber balls, arranged in sockets near the lower part of the car, are supported on their seats in a state of rest; but the instant that the rope breaks or gets detached from the bolt the action of a spiral spring throws an actuating plate downward, and levers and ball-carrying rods upward. The balls are thus thrown off their seats and wedged between the inclined sides of the pockets and the guide posts of the elevator so as to stop thereby the car.

IMPROVED COMBINATION LOCK.

Achille Parise, Naples, Italy.—This is a new combination lock for doors, trunks, safes, etc., that admits of a large number of combinations, and may be opened and closed quickly. It consists of sliding tumbler plates, having longitudinal slots and a number of perforations placed at different relative positions to the slots of each tumbler. The trunks are connected by screw set pins attached to face slides, and passing through any one of the perforations, admitting the setting of the tumblers and opening of the lock by outer projections or buttons of the slides to fixed exterior guides.

IMPROVED MACHINE FOR WIRING AND BINDING HATS.

Mari A. Cuming and Judson Knight, New York city.—This is a machine for binding hats, felt skirts, and similar articles, by a uniform and parallel pressure on the rims, and by facilitating the applying and taking off of the articles from the machine, and accomplishing the cutting of the binding or braid and wire in a reliable and improved manner. Pressure rollers attach the binding and the wire, if one is required, in connection with a grooved gage that is supported on a seat of the shaft of the lower pressure roller. The wire is guided by annular recesses or chamferings at the rear circumference of the pressure rollers and the groove of the gage. The gage is so connected to its seat that it may be turned and another guide groove of the same be exposed to face the pressure rollers, so as to adapt the same for a variety of work.
