THE ELECTRIC MOTOR TESTS ON THE NEW YORK ELEVATED RAILROAD.

The American Institute of Electrical Engineers at its last meeting of the season, held June 25, again considered the subject of electrical traction, the paper presented by Mr. Leo Daft being based upon some recent electrical work on the elevated railroads and its bearing on the rapid transit problem. The Railroad Gazette gives the following abstract:

He introduced the subject with a tribute to the efficiency of the elevated railroad system as it is now operated by steam, with special reference to that section of it known as the Ninth Avenue line, upon which his experiments with the electric motor have been conducted, over which passengers are now conveyed a distance of five miles in 26 minutes for five cents, which he considered the best and cheapest municipal rapid transit in the world, and which is operated with a higher degree of safety than any other railroad in the world making an equal number of stops per 100 miles. On a recent holiday, April 30 last, 835,720 passengers were carried upon the entire system without noticeable detention or accident. The rapidly increasing traffic makes the demand for better facilities a pressing one, and as the average half million now carried daily will soon become a million, it appears doubtful if any method can be devised of providing for the growth by the use of steam motors on the present structures, which are now taxed to their utmost. To the mind of the mechanical engineer, having in view the ordinary coefficients of tractive ability, there is no remedy for this. The speaker stated that these coefficients were not entirely trustworthy. He reiterated his previously expressed opinion, based on frequent experiments, that there is a decided increase in traction gained by the passage of the electric current from the wheels to the rails, giving the details of one test where a motor with a load making a total of 600 lb. climbed a gradient of 2,900 ft. per mile, starting from a state of rest. He stated that some of those people who had ridiculed his statements had finally admitted that they were true.

The motor Ben Franklin, which had been used in making these tests on the elevated roads, weighed 10 tons, and performed service nearly equal to the steam motors weighing 18 tons. The object of these tests was the determination of coal economy. Tests with a Prony brake showed that the motor developed 128 H.P. The piece of track on which the experiments were conducted embraced 2,200 ft. of level track and 1-8/10 miles of gradients, varying from 11-3/10 to 98-7/10 ft. per mile, while at Thirtieth street the station is at the foot of the steepest grade, thus testing to the utmost the tractive capacity of the motor. The experiments were begun in October, 1888, and carried on between the hours of 9 P.M. and 4 A.M., beginning with one or two cars, the load being increased nightly until it was finally made up of eight coaches of 12 tons each, which were hauled up the 98 ft. grade at a speed of 7½ miles per hour, the entire distance being covered at the rate of 14-6/10 miles per hour. The maximum speed obtained on level with that train was 16.36 miles per hour. Seventy trips were subsequently made with a 70 ton train operated between the steam trains under 3 minutes headway, but the work was considered too critical on account of the absence of suitable brakes. A number of experiments made about this time showed that the mean speed with a three-car train running express on the up-town track was about 24 miles per hour, although the ability of the motor on a level with a similar train was nearly 28 miles per hour. This, however, was not the maximum speed, as the level track was not long enough to permit of its attaining the highest rate. It was the opinion of the speaker, however, that the speed attained could not be exceeded with prudence on the elevated structure.

The measurements of speed were made by dividing the track into 19 sections of 500 ft., each section being provided with a circuit-closing plate connected with a chronograph which was carefully tested. The indicator cards were taken at the central station by Mr. Idell and his assistants, and the dynamometer used was of the liquid type made by Mr. Shaw, of Philadelphia. The diagrams prepared from the data obtained were then explained by the speaker, who stated that there was not a marked difference between the 10 ton motor and the 18 ton locomotive in the initial effort on the level, as will be seen by comparing a run observed by a railroad officer on March 9 with a steam motor and a load of about 57½ tons. The steam motor required 1 min. and 29 sec. to make the distance from 14th to 23d streets, while the electric motor with a train of 70 tons made the same trip in 1 min. and 50 sec.; the absence of power brakes compelled the current to be taken off at 19th street, while it was probable that the throttle of the steam locomotive was not closed until it reached 23d street, this being the usual practice. The data obtained in these experiments shows that 29,940 h.p. is required to operate the Ninth avenue railroad for the 16 hours' service, or an average of 1,871 h.p. per hour, or 2,181 h.p., adding station friction. The varying requirements of the traffic during the day shows that the service could be advantageously divided up between four stationary engines of 800 h.p. each, there being but five hours of the day when all of them would be required. The fuel consumption per day, allowing 22 lb. of coal per h.p. per hour at $2.25 per ton, would make a total of $92.25 per diem for fuel, the coal being a mixture deliverable at the dock for about $1.80 per ton. The weight of coal used for the present locomotives is about the same, viz., 40 tons per day, but practice has shown it to be most economical to use coal of the best quality, costing $5 per ton, making the cost of fuel about double that required for the electric system. Without entering into other economies which the speaker claimed were in favor of electricity, and ignoring the plan suggested by Sir William Siemens of braking the train by converting the motor into a dynamo and thus utilizing the energy of momentum, he believed that the economy in fuel alone was sufficient to prove that the application of power by electricity was preferable to direct steam propulsion for the elevated railroad service.
