The Edison Carbon Telephone and Hughes' Microphone.

To the Editor of the Scientific American:

Mr. Edison finds a resemblance between his carbon telephone and my microphone.

I can find none whatever; the microphone in its numerous forms that I have already made, and varied by many others since, is simply the embodiment of a discovery I have made, in which I consider the microphone as the first step to new and perhaps more wonderful applications.

I have proved that all bodies, solid, liquid, and gaseous, are in a state of molecular agitation when under the influence of sonorous vibrations; no matter if it is a piece of board, walls of a house, street, fields or woods, sea or air, all are in this constant state of vibration, which simply becomes more evident as the sonorous vibrations are more powerful. This I have proved by the discovery that when two or more electrical conducting bodies are placed in contact under very slight constant pressure, resting on any body whatever, they will of themselves transform a constant electrical current into an undulatory current, representing in its exact form the vibrations of the matter on which it reposes; it requires no complicated arrangement and no special material, and to most experimenters the three simple iron nails that I have described form the best and most sensitive microphone. But these contact points would soon oxidize, so naturally I prefer some conducting material which will not oxidize.

Mr. Edison's carbon telephone represents the principle of the varying pressure of a diaphragm or its equivalent on a button of carbon varying the amount of electricity in accordance with this change of pressure; it represents no field of discovery, and its uses are restricted to telephony.

The three nails I have spoken of will not only do all, and that far better than Edison's carbon telephone in telephony, but has the power of taking up sounds inaudible to human ears, and rendering them audible, in fact a true microphone; besides it has the merit of demonstrating the molecular action which is constantly occurring in all matter under the influence of sonorous vibrations.

Here we have certainly no resemblance in form, materials, or principles to Mr. Edison's telephone. The carbon telephone represents a special material in a special way to a special purpose.

The microphone demonstrates and represents the whole field of nature; the whole world of matter is suitable to act upon, and the whole of the electrical conducting materials are suitable to its demonstrations.

The one represents a patentable improvement; the other a discovery too great and of too wide bearing for any one to be justified in holding it by patent, and claiming as his own that which belongs to the world's domain.

London, July 2, 1878. D. E. HUGHES.

New Industrial Enterprises.

The increasing wealth of a nation, as well as the profitable and steady employment of its capital and people, depends upon a continual increase of the producing power. Whenever there are latent resources undeveloped or opportunities for establishing the first foundation of an industry, leading as it will to the originating of hundreds of auxiliary ones, an unusual effort should be made to bring it into existence. If in the power of individuals to accomplish, so much the better; if needing an association with State or national influence, then this association should be formed. It is incumbent upon individuals that they possess a sufficient pride in the prosperity of the country to give every possible attention and assistance to a careful practical demonstration of the feasibility of all the new industrial enterprises which may be presented with reasonable assurance of final success.

Not in a great expenditure of money: influence is better than money, and a potential interest in a new enterprise is often better than capital. The industrial resources of the United States are by no means worked to their full capacity. The people by no means make all they consume. The finer articles of use, and requiring much labor and often the highest skill, are imported from foreign nations. A premium of $10,000 offered for an improved method in any known present process of production or manufacture would be almost sure to be called for.

While America exports $175,000,000 worth of raw cotton annually to be worked up by other people, is it not possible to so increase the manufacture in America as to keep the greater part of that raw material and to export the cloth instead? Is it not practicable to establish great numbers more of sugar estates in the same tropical climate? Is it not practicable to lay the foundation of half a dozen beet sugar mills in the country? To begin the weaving of linen goods, and to teach our farmers that they may produce all the flax fiber as fast as required? To start a ramie industry in a small way and teach the process to those who will engage in it?

Will not our silk men put a velvet industry into operation as a germ from which a future industry may grow? And we might name a hundred other lesser enterprises which have hardly name in this country, but every one of which is needed and will add to the wealth of the people.

Replanting and Transplanting Teeth.

Dr. G. R. Thomas, of Detroit, in the current number of the Dental Cosmos, states that this operation of "replanting" has become so common with him, and the results so uniformly satisfactory, that he does not hesitate to perform it on any tooth in the mouth, if the case demands it; and he finds the cases that demand it, and the number that he operates upon, continually multiplying.

He makes it a point to examine the end of the roots of nearly all his cases of abscessed teeth; and a record of more than 150 cases, with but one loss (and that in the mouth of a man so timid that he utterly refused to bear the pain which nearly always follows for a few minutes, therefore necessitating re-extraction), convinces him that the operation is not only practical, but decidedly beneficial to both patient and operator. For one sitting is all that he has ever really found necessary to the full and complete restoration of the case.

In the present article, however, Dr. Thomas states that it is his object not so much to speak of replanting as of transplanting, which he has reason to believe is just as practical, so far as the mere re-attachment is concerned, as is replanting. He details, in illustration, a case in which he successfully performed the operation; inserting in the mouth of a gentleman, who had lost a right superior cuspidate, a solid and healthy tooth that he had removed from a lady's mouth four weeks previously. He opened into canal and pulp chamber of the tooth, from the apex of the root only; cut the end off one eighth of an inch (it being that much too long), reduced the size somewhat in the center of the root (it being a trifle larger than the root extracted), filled and placed it in position. He states that the occlusion, shape, and color were perfect, so much so that several dentists who saw the case were not able to distinguish the transplanted tooth from the others. The two features in the case that he calls particular attention to are: first, that although the tooth had been in his office four weeks, there is to-day no perceptible change in color; and second, that the re-attachment is as perfect as though it had been transplanted or replanted the same day of extraction. The operation was performed about three months ago. Dr. Thomas knows of but two obstacles in the way of the perfect practicability of "transplanting:" first, the difficulty of obtaining the proper teeth at the proper time; and second, the possibility of inoculation. The latter is the more formidable of the two, and, to escape the ills that might follow, the greatest caution is necessary. The first difficulty is more easily gotten over, for it is not necessary that the tooth transplanted should correspond exactly in shape and size to the one extracted; if it is too large, it may be carefully reduced; or if too small, new osseous deposit will supply the deficiency. Neither is it necessary, as we have seen, that the transplanted tooth should be a freshly extracted one.

As a demonstration of what modern dental surgery is capable of performing Dr. Thomas' statements are very interesting; it is doubtful, however, whether popular prejudice will allow this practice of "transplanting" to become of much use.

American Institute Exhibition.

For forty-seven years the American Institute of New York has opened its doors and invited American inventors and manufacturers to exhibit their productions; and again this year it renews its invitation to all. To such as wish to reach the capitalist and consumer, they must admit that New York is the place. For details apply to the General Superintendent by mail or otherwise.

On the 22d of June, cloud bursts occurred in the mountains northeast of San Buenaventura, Cal., causing the Ventura river to pour down such a volume of muddy water that the ocean was discolored for a distance of six miles.
