NEW MISCELLANEOUS INVENTIONS.

APPARATUS FOR THE HYDRATION OF CHLORINE GAS.

William Maynard, New York city.—This invention relates to an improved construction of apparatus for the hydration of gases, and more particularly chlorine gas for the manufacture of chlorine water for use in the industrial arts of bleaching, etc. It consists mainly in a case having an inlet for the water above, an inlet for the gas below, and provided with an intermediate water percolating medium; combined with a reservoir located below the level of the case and having a water-sealed communication therewith, which reservoir receives the hydrated gases, and which water seal prevents the heavy gas in the case from passing out through the bottom inlet. The case for the percolation of water and the absorption of the gas is made of conical shape, with the largest diameter at the bottom, to produce the greatest absorption of the heavy gas when first admitted; while horizontal partitions, or shelves, in said case are provided with upwardly projecting tubes which hold a permanent surface of water on the said partition or shelves. The tubes permit, by their peculiar shape, the water to pass down on one side and the gas up on the opposite side of said tube, while their alternating arrangement in the alternating shelves gives a zigzag and long continued passage to the gas and water in moving in opposite directions through the case.

IMPROVED PROCESS OF PREPARING GAS FUEL.

Martin N. Diall, Terre Haute, Ind.—This inventor saturates wood by immersing it in any hydrocarbon oil for from six to twelve hours, as required by the nature of the wood, so that it may take up the necessary quantity of oil for the required strength of gas. The wood is then immersed in a bath of water, for taking up a quantity of water outside the oil, and is then charged in the retorts, the same as coal, and distilled in the same way. By this process the inventor claims that he produces fixed gas equal to coal gas, much faster, and with less expense, the wood and water furnishing the hydrogen, and the oil furnishing the carbon.

IMPROVED FISHING LINE LEADER.

Welmer T. Jahne and Anthony Moors, Jersey City, N.J.—This consists of a leader made of spring wire, bent into V form, provided with a swivel and eye at its middle part, and with eyes or loops at its ends to receive the line and snells. By this construction the snells and hooks will be kept apart however the line maybe thrown, and however they and the leader may be turned about by the tide or current. The device is one well calculated to meet with a favorable reception from fishermen.

IMPROVED ABDOMINAL CORSET.

Christina Lascell, Newark, N.J.—The object of this invention is to furnish an improved abdominal corset, which supports the weight of the abdomen in a perfectly comfortable and easy manner, and throws the strain on the shoulders and hips of the wearer. The corset is adjustable to the varying conditions of the abdomen, does not interfere with the motion and different positions of the body, and is readily put on and taken off. It has adjustable elastic shoulder straps, and opening at the sides by lacings and elastic bands and buttons. The front part of the corset is stiffened by a stay that slides in a pocket to provide for stooping. A central front and lacing admit the front part of the corset to expand. The lower extension part of the corset has short stiffening stays, and it is connected independently of the upper stays by short side lacing and elastic straps to the side or hip parts of the corset. A hernial band extends from the lowermost part of the corset-extension between the legs to the rear, and is attached by adjustable hip straps to the sides of the corset.

IMPROVED FIRE ESCAPE.

John F. Werner, New York city.—The terrible disaster in the Brooklyn theater is serving as a stimulus to induce the invention of devices looking to the prevention of a like occurrence. The present inventor has devised a new fire escape for theaters, concert halls, and other public places of amusement, by which the space at the upper parts of the entrances, halls, or vestibules of the buildings is utilized for the purpose of forming additional passage ways for the persons in the buildings, to be used in case of fire for the more convenient and less dangerous exit of the same. The invention consists, mainly, of a movable floor, suspended by chains, pulleys, and weights, near the ceiling of the entrances, and lowered in case of fire. It is supported on projecting rests of the side walls, at suitable height above the floor. Sliding extensions and swinging stairs and rear sections connect with the ground outside of the door, and with the staircases of the gallery, so as to form separate exits above the regular entrances.

IMPROVED ELECTRO-MAGNETIC DENTAL PLUGGER.

James E. Dexter, New York city.—This invention consists, first, in a magnet having a centrally bored iron core, surrounded by a magnetic coil, which is enveloped by an iron shell that is concentric with the central core, and is attached to a flange formed on the lower end of the said central core. One side of both shell and core are split for the purpose of obviating residual magnetism. The invention also consists in combining a spring yoke, a vibrator, and a spring contact piece, as hereinafter particularly described. The third part of this invention consists in the arrangement of the key for completing the circuit, which is made with an insulating exterior, and is provided with one of the termini of the magnet coil, and bears against the side of the key to insure a constant contact of the surfaces. The various parts of the plugger are combined, so that pressing the key with the finger makes the circuit, and a succession of regular strokes is produced, the force of which may be varied by an adjusting screw.
